White-Rodgers 24A34-1 24V Electric Heat Sequencer, SPST

Save 56%
Original price $26.98
Current price $11.80
SKU 24A34-1
Currently 80 in stock.

White-Rodgers 24A34-1 24V Electric Heat Sequencer, SPST

Direct replacement for most fan/heat sequencing functions. Terminal markings are equivalent to competitive types.

  • Replaces Honeywell, MARS, TOD, GEMLINE, Klixon (Texas Instruments)
  • 24V input control
  • Multi-poise mounting
  • Any contacts (except M1 & M2) can be used as auxiliary contacts
  • Double quick-connect terminals for combination loads



    Installation Instructions



    Specifications

    Timings: 1
    Switch Description: 1
    Timings-On In Seconds: 1 to 20, Switch M1-M2
    Timings-Off In Seconds: 40 to 110, Switch M1-M2
    Amperage: 14.0 FLA, 72.0 LRA, 25.0, 3000W Res at 120 Vac, 7.0 FLA, 42.0 LRA, 25.0, 6000W Res at 240 Vac, 12.5, 6000 Res at 480 Vac
    VA Output: 120-240 Vac 125 VA, 480 Vac 480 VA
    Ambient Operating Temperature Range: From -50 to +165°F
    Approvals: U.L. component recognized
    Inductive (Motor) Full Load 120 Vac: 14.0A
    Inductive (Motor) Full Load 240 Vac: 7.0A
    Inductive (Motor) Locked Rotor 120 Vac: 72.0A
    Inductive (Motor) Locked Rotor 240 Vac: 42.0A
    Inductive (Motor) Locked Rotor 480 Vac: 25.0A, 3000W
    Inductive (Motor) Locked Rotor 480 Vac: 25.0A, 6000W
    Inductive (Motor) Locked Rotor 480 Vac: 12.5A, 6000W
    Pilot Duty: 120-240 Vac 125 VA, 480 Vac 480 VA
