US Motors 5464 Rescue 5.6" Condenser Fan Motor, 208-230V, 1/3-1/6 HP, 825 RPM

Save 29%
Original price $182.00
Current price $128.77
SKU 5464

US Motors 5464 Rescue 5.6" Condenser Fan Motor, 208-230V, 1/3-1/6 HP, 825 RPM

The Ultimate Truck Stock Motor

What is a Rescue® Motor?

  • Universal Replacement Motor for Condenser Fan and Direct Drive Blower Applications
  • Multi-Horsepower PSC Motors
  • Flexible Mounting Options
  • Permanent Replacement Motors – There is no need to go back
  • Designed to Allow Contractors to Stock Fewer Motor Models On Their Truck While Increasing the Service Level to Their Customers



How Does Multi Horsepower Work?

  • A PSC Motor’s output RPMs vary based upon the driven load.
    • Increases in loading will reduce the RPMs
    • Decreases in loading will increase the RPMs towards Synchronous
  • Specifically Designed Motor Windings and Speed Taps to Match HP Requirements and Speed for Each Application.
  • Each Motor has More Copper (Windings) and Iron (Rotor Core) to Prevent Overheating.
  • This Makes RESCUE® Motors Stronger



Condenser Fan Motor Features

  • Permanent Split Capacitor (PSC) Design
  • Totally Enclosed Air Over (TEAO)
  • Automatic Thermal Protector
  • Ball Bearings
  • Reversible Rotation
  • 48 Inch Leads
  • All Angle Mounting
  • Mounts by Thru-bolts, Belly Band (with Kit), Four Holes in the Shell or Four Blind Holes in the end shield. (New Screws Incl.)
  • 60°C (140°F) Ambient Rated



SPECIFICATIONS
HP: 1/3 - 1/6
Voltage: 208-230
Max. Ambient: 140°F (60°C)
RPM: 825
Speeds: 2
Bearings: Ball
Amps: 1.9
Phase: 1
Rotation: Reversible
