US Motors 5462H RESCUE MOJAVE 5.6" Condenser Fan Motor, 208-230V, 1/3-1/6 HP, 1075 RPM

Save 31%
Original price $153.00
Current price $105.85
SKU 5462H

US Motors 5462H RESCUE MOJAVE 5.6" Condenser Fan Motor, 208-230V, 1/3-1/6 HP, 1075 RPM

The Ultimate Truck Stock Motor

What is a Rescue® Motor?

  • Universal Replacement Motor for Condenser Fan and Direct Drive Blower Applications
  • Multi-Horsepower PSC Motors
  • Flexible Mounting Options
  • Permanent Replacement Motors – There is no need to go back
  • Designed to Allow Contractors to Stock Fewer Motor Models On Their Truck While Increasing the Service Level to Their Customers



How Does Multi Horsepower Work?

  • A PSC Motor’s output RPMs vary based upon the driven load.
    • Increases in loading will reduce the RPMs
    • Decreases in loading will increase the RPMs towards Synchronous
  • Specifically Designed Motor Windings and Speed Taps to Match HP Requirements and Speed for Each Application.
  • Each Motor has More Copper (Windings) and Iron (Rotor Core) to Prevent Overheating.
  • This Makes RESCUE® Motors Stronger



Condenser Fan Motor Features

  • High 158°F (70°C) Ambient Design
  • Automatic Reset Thermal Overload Protector
  • Designed For Use With 370V Capacitors
  • Special Treated Rotor For Corrosion Protection
  • Includes Lead End Mounting Holes For RHEEM or TRANE Units
  • 48" Leads
  • Extended Mounting Studs
  • Ball Bearings
  • Reversible Rotation
  • High Efficiency Design
  • Continuous Duty, Air Over



SPECIFICATIONS
HP: 1/3 - 1/6
Voltage: 208-230
Max. Ambient: 158°F (70°C)
RPM: 1075
Speeds: 2
Capacitor MFD: 5.0
Bearings: Ball
Amps: 2.6
Phase: 1
Rotation: Reversible
