US Motors 5460 Rescue 5.6" Direct Drive Blower Motor, 115V, 1/2-1/6 HP, 1075 RPM

Save 35%
Original price $148.00
Current price $96.27
SKU 5460

US Motors 5460 Rescue 5.6" Direct Drive Blower Motor, 115V, 1/2-1/6 HP, 1075 RPM

The Ultimate Truck Stock Motor

What is a Rescue® Motor?

  • Universal Replacement Motor for Condenser Fan and Direct Drive Blower Applications
  • Multi-Horsepower PSC Motors
  • Flexible Mounting Options
  • Permanent Replacement Motors – There is no need to go back
  • Designed to Allow Contractors to Stock Fewer Motor Models On Their Truck While Increasing the Service Level to Their Customers



How Does Multi Horsepower Work?

  • A PSC Motor’s output RPMs vary based upon the driven load.
    • Increases in loading will reduce the RPMs
    • Decreases in loading will increase the RPMs towards Synchronous
  • Specifically Designed Motor Windings and Speed Taps to Match HP Requirements and Speed for Each Application.
  • Each Motor has More Copper (Windings) and Iron (Rotor Core) to Prevent Overheating.
  • This Makes RESCUE® Motors Stronger



Direct Drive Blower Motor Features

  • Permanent Split Capacitor (PSC) Design
  • Open Air Over (OAO)
  • Automatic Thermal Protector
  • Self - Aligning Sleeve Bearing
  • Reversible Rotation
  • 36 Inch Leads
  • All Angle Mounting – Vertical or Horizontal
  • Mounts by Thru-bolts, Belly Band (With Kit), or Eight Holes in the Shell for Brackets, Including Rheem and Trane Special Mounting



SPECIFICATIONS
HP: 1/2 - 1/6
Voltage: 115
RPM: 1075
Speeds: 4
Bearings: SAB
Amps: 7.3
Phase: 1
Rotation: Reversible
