UEi C161 Residential Combustion Analyzer

Save 15%
$647.00
$549.95
SKU C161
Currently 1 in stock.

UEi C161 Residential Combustion Analyzer

Flue Gas Analyzer with Direct CO2 Measurement

The C161 Residential Combustion Analyzer, with EOS Technology, eliminates the number one hassle experienced by HVAC technicians, the cost and down time of replacing the O2 sensor. The EOS award-winning technology for combustion analysis replaces the everyday electro-optical sensor with EOS CO2 technology, lowering the cost of ownership. The C161 offers direct CO2 measurement and features a 30 second start up time.

Backed by UEi Service+ to give up to 6 years’ warranty, next day recertification, and a reduced cost of ownership. The C161 Residential Combustion Analyzer is easy to use with a rugged design, multiple sensor protections, altitude compensation and a heat exchanger test.

  • Prints to optional printer.
  • Essential information for installing and maintaining furnaces and boilers in one device.
  • Up to 6-Year warranty with annual recertification
  • Eligible for UEi Service+
  • Large 6-line backlit display
  • Heat Exchanger Test
  • 2 levels of sensor protection
  • NOx filtered CO sensor
  • Low flow detection
  • High altitude compensation
  • Differential temperature with K/Type probes
  • Protective water trap

    Functions

    CO : 2000 ppm
    CO2 : 20%
    O2 : 21%
    Flue temperature : 32˚ to 1112˚F
    Inlet temperature : 32˚ to 1112˚F
    Differential Temperature : Yes

    Features

    Low battery warning : Yes
    Backlight : Yes
    Temperature Inputs : K-Type
    Temp differential : Yes
    Protective boot or overmolding : Yes
    Sensor Technology : EOS
    Preprogrammed Fuels : 8
    Start time : 30 second
    High altitude compensation : Yes
    Memory Positions : 30
    Magnetic mount : Yes
    Warranty : 1-Year limited
    Recording/Data Logging : Yes
    K-type input : Yes
    Digital : Yes
    Number of display parameters : 6 line
    IR printer link : Yes
    LED Full water Trap Indicator : Yes
    NOx Filtered : Yes



    Includes

    Quick Start Guide : Yes
    Batteries : Rechargeable 3 (AA)
    Flue probe : CP2
    USB cable : Yes
    Charger : WIR00067



    Standards

    CE Conformity : Yes
    RoHS : Yes
    REACH Compliant : Yes
    AHRI 1260 Standard : Yes
