Supco SHP600475 High Pressure Control Switch, 600-475 PSI
$11.99
SKU SHP600475
Supco SHP600475 High Pressure Control Switch, 600-475 PSI
- ¼" SAE 45° female flare fitting with valve core depressor
- Excellent set point repeatability/stability
- High pressure switch opens on pressure rise
- Life at rated load: 100,000 cycles
- Rated Voltage 24/120/240 VAC @ 50/60 Hz
- Small size and light weight for direct mounting
- Snap acting stainless steel hermetically sealed sensor
- Wire is 18 AWG, 18" long
Specifications
|
DC Voltage: |
6Vdc/12Vdc/36Vdc |
| Open PSI: | 600 PSI |
| Tolerance: | +/- 15 PSI |
| Close PSI: | 475 PSI |
| Burst Pressure: | 2800 PSI |
| Maximum Operating Pressure: | 700 PSI |
| Maximum Temperature: | -31°F to 149°F (-35°C to 65°C) |
| Maximum LRA: | 17.4 Amps @ 240VAC |
| Maximum LRA: | 34.8 Amps @ 120VAC |
| Maximum FLA: | 2.9 Amps @ 240VAC |
| Maximum FLA: | 5.8 Amps @ 120VAC |
