Supco 9071 Potential Relay 420 Continuous Coil Voltage

$12.95
SKU 9071

Supco 9071 Potential Relay, 420 Continuous Coil Voltage


• Industry standard part numbers used by most compressor and equipment manufacturers
• Universal break-off mounting bracket
• Contact rating 35 Amp @ 277 VAC
• Non-positional
• Voltage Sensitive Relay
• Instant Re-start
• Safety Time Delay
• Use with any size suitable start capacitor

 Continuous Coil Voltage:   420
 Pick-up Min.:   223
 Pick-up Max.:   259
 Drop-out Max.:   121

This part replaces Mars 190010

**All warranty claims will be handled according to the Supco, Inc. warranty policy.**
