Resideo Braukmann VWS01Y-3/4 L5 WiFi Leak Shutoff with 3/4" NPT Ball Valve, includes L1 WiFi Leak Detector

$231.08
SKU VWS01Y-3/4
Currently 2 in stock.

Resideo Braukmann VWS01Y-3/4 L5 WiFi Leak Shutoff with 3/4" NPT Ball Valve, includes L1 WiFi Leak Detector

The smarter way to help prevent water damage.

Thanks to advancing technology, you can enjoy safer, smarter, more connected homes. The Resideo Braukmann L5 WiFi Water Leak Shutoff Valve is a perfect example. When a water leak is detected from the included L1 WiFi Water Leak Detector, this device automatically shuts off the water flow at the source, protecting the home from potentially expensive damage.

Whether out of town or out for the evening, the Resideo Braukmann L5 WiFi Water Leak Shutoff Valve responds to water alerts with an automatic shutoff response. Both the Shutoff Valve and the included L1 WiFi Water Leak Detector send alerts via mobile phone and email when the Shutoff Valve or the connected detects a leak, helping safeguard your belongings and the home’s structure from potential costly repairs. It’s a vital part of your home water control system that provides added peace of mind.

FEATURES

  • Connected and in control
    • The Resideo App can be setup as a water leak detection control panel with notifications, customized alerts, and pre-set shutoff locations. The wireless functionality means customers can control their home's water from anywhere.
  • Automatic and accurate
    • The Shutoff Valve shuts off the home's water supply when it detects water via the 5-ft sensor cable attached to the device. Extend the leak detection range up to 500-ft by adding additional Sensor Cables.
  • Even better together
    • Easily pair the Shutoff Valve with any Resideo WiFi Water Leak and Freeze Detectors for reliable water leak detection and an automatic shutoff response.
  • A legacy of quality
    • For over 100 years, Braukmann has built a reputation for providing a complete portfolio of reliable water solutions for contractors and homeowners.
  • Be their pro
    • Customers can set alerts on the Resideo App to notify them of any leak or shutoff events and provide the support they need right away.



Sell Sheet

Specification Data Sheet

Resideo Braukmann Brochure

Installation Instructions

Quick Start Guide

Submittal Sheet



Specifications

Application: Water Leak Detection, Water Shut off Valve
Dimensions: 5.16 in H x 4.61 in L X 2.67 in W
Includes: L5 Actuator, Lead-free Ball Valve, Power Supply Adapter, Actuator to Ball Valve Metal Clip, Water Leak Detector Cable, Separate Water Leak Detector and Cable
Product Features: Auto Shutoff Through Water Leak and Freeze Sensor, Control the L5 WiFi Water Leak Shutoff Valve Remotely Via the App, Manual Override to Turn On or Off Water, Easy Install
Mounting Location: Install the L5 Water Valve on the main water line after the main water shutoff valve and the pressure reducing valve (if applicable).
Mounting Option: Valve can be installed in any orientation
Wireless Connectivity: WiFi frequency band of 2.4GHz, 802.11 b/g/n, Bluetooth 4.1
Approvals and Standards: CE EMC 2014/30/EU, CE RED 2014/53/EU, EN 60730-1, EN 60730-2-14, UKCA, CAN/CSA C22.2, UL 60730-1, UL 60730-2-14, WEEE 2012/19/EU, ES 116, RoHS 2011/65/EU, ES 50040083, REACH 1907/2006, Proposition 65, FCC part 15, subpart C, RSS-247
Voltage: 100 to 240 V
Ambient Operating Temperature (Max): 113 °F, 45 °C
Ambient Operating Temperature (Min): 32 °F, 0 °C
Connection Type: NPT
Pipe Size: 3/4 in.
Fluid Temperature (F): 36 °F to 149 °F
Available Accessories: Leak Detector Cable; WiFi Water Leak and Freeze Detector, Spare Actuator, Spare Power Cable, Spare Valve
