Ranco ETC-111000-000 Single Stage Electronic Temperature Control, 120/208/240V

The Ranco® ETC Series Electronic Temperature Control offers a full-featured electronic replacement for electrical-mechanical temperature controls used in many commercial refrigeration applications. With its wide temperature range, one and two stage capability, selectable heating/cooling modes and multi-voltage input, the ETC is designed to provide application flexibility.

Features and Benefits

• Anti-short cycle compressor delay for cooling applications
• Wide temperature range (-30°F to 220°F) (-34.4°C to 104.4°C)
• Wide differential adjustment (1°F to 30°F)
• LCD read-out for sensor temperature, control settings, and relay status
• High Amp output relay (FLA 16 Amps @ 120V AC and 8 Amps @ 208/240V AC) single stage
• EEPROM memory retains control settings during power outages
• Keypad lockout to prevent end-user alteration of settings
• 8 foot lead with sensor is extendable up to 400 feet using 18 or 22-gauge thermostat wire
• Easy 4-step set-up
• Heavy-duty relay is 1 HP rated
• Selectable °F or °C heating/cooling modes
• Single and two stage models
• NEMA 1 case and cover
• NEMA 4X models available
• White backlight on display
• Sensor rated IP67 for dust and water (<1m) resistance

Specifications

Cross Reference
