Ranco A22-1129 Ice Machine Bin Level & Harvest Control
Save 14%
Original price
$105.98
Current price
$90.66
SKU A22-1129
Ranco A22-1129 Ice Machine Bin Level & Harvest Control
The Ranco® A22, A30 and 9530 Series Constant Differential Temperature Controls are designed to switch electrical components of refrigeration systems in response to sensed temperatures.
Features and Benefits
- Laser-welded stainless steel bellows
- Fixed or adjustable temperature settings
- High-amperage contacts
- Pneumatic action provided by vapor-filled capillary or capillary with bulb sensing elements
- Constant On or Off positions available
- Choice of mounting brackets, adjustment ranges and cams, and slotted or flatted shafts
- Standard 1/4” quick-connect terminals with optional screw terminals
Specifications
| Series Application: | A22/A30 Series Ice Bin Level and Harvest Control |
| Switch: | SPDT |
| Sensing Element: | 48" Capillary |
| Capillary Length: | 48" |
| Adjust Type: | Dial |
| Application: | Bin Level Control |
| Cold On: | NA |
| Cold Off: | NA |
| Differential: | 6°F |
| Normal Off: | 35°F |
| Normal On: | 51°F |
| Warm On: | NA |
| Off Position: | NA |
