DiversiTech Littelfuse FLSR060T 60 Amp, 600V, TD, Class RK5
Littelfuse FLSR060T, 60 Amp, 600V Dual-Element, time-delay UL Class RK5 fuses are the most widely used fuse class. They offer superior performance and excellent protection for all types of circuits, especially those with motors.
Product Features & Benefits:
- Excellent short-circuit protection
- Dual-element design
- Current-limiting
Specifications:
- Ducted or Ductless: Both Ducted and Ductless
- Primary Depth: 5.5 in
- Primary Width: 1.06 in
- Primary Height: 1.06 in
|
Current Rating (Continuous) in Amps:
|
60
|
|
Interrupting Rating:
|
20 kA @ 300 Vdc
|
|
Opening:
|
Slo-Blo/Time Lag (T)/Time Delay
|
|
Maximum AC Voltage (V):
|
600
|
|
Voltage Rating (V):
|
300
|
|
Size:
|
Industrial Cartridge
|
|
Family style:
|
Dual Element Fuse
|
|
Fuse Class:
|
Class RK5
|
|
Indicating:
|
No
|
|
Interrupt Amperage:
|
200000
|
|
interrupt Amperage (A) - 2:
|
300000
|
|
Interupt Amperage 3:
|
20000
|
|
Interrupt Voltage Type ACDC - 1:
|
AC
|
|
Interrupt Voltage Type ACDC - 2:
|
AC
|
|
Interupt Voltage Type ACDC - 3:
|
DC
|
|
Interrupt Voltage:
|
600
|
|
interrupt Voltage (V) -2:
|
600
|
|
Interupt Voltage - 3:
|
300
|
|
Mounting Method:
|
Fuse Block / Clip / Holder
|
|
PG Holder:
|
LFR60060 Series
|
