Ranco A12-700 Constant Cut-in Cold Temperature Control, 37°F
Save 40%
Original price
$119.25
Current price
$71.88
SKU A12-700
Ranco A12-700 Constant Cut-in Cold Temperature Control, 37°F
The Ranco® A12 and 9531 Series Constant Cut-in Temperature Controls are designed to switch electrical components of refrigeration systems in response to sensed temperatures.
Features and Benefits
- Laser-welded stainless steel bellows
- Fixed or adjustable temperature settings
- High-amperage contacts
- Pneumatic action provided by vapor-filled capillary or capillary with bulb sensing elements
- Constant On or Off positions available
- Choice of mounting brackets, adjustment ranges and cams, and slotted or flatted shafts
- Standard 1/4” quick-connect terminals with optional screw terminals
Specifications
| Series Application: | A12 Series Constant Cut-In Control |
| Capillary Length: | 84" |
| Cut-In: | 37°F |
| Normal Off: | 18°F |
| Warm Off: | 26°F |
Cross Reference
| Alco Food Prep.: | 38898, 39375-5, 800313 |
| Alliance Refrig. Mfg.: | P2375 |
| Barr Mfg. Co.: | A12-1674 |
| Blissfield Mfg. Co.: | BE-1027-B, BE-1032-B, BE1032-B, BE-302-A, BE-302-B, BE-395-A, BE-395-B, BE-411-B, BE-617-B, BE-758, BE-804-B, BE-986-B |
| Cavalier: | C3186, C-4-2968, C-4-3071, C-4-3087, C-4-3330 |
| Choice Vend.: | 851087, 854736, 863160, 863160, 863160H, 863160L, 868874, 868874W |
| Cornelius Avenco: | 33-2410-000 |
| Cutler Hammer: | 9531N112, 9531N126, 9531N132, 9531N134, 9531N135, 9531N139, 9531N140, 9531N141, 9531N169, 9531N175, 9531N204, 9531N208, 9531N252, 9531N272 |
| Dixie: | 802-800-090.11, 802-800-090.31, 802-800-160.01, 802-800-160.11, DN28-0016 |
| GE (General Electric): | 3ART6G68 |
| Gemline: | GA12700 |
| Glasco / Univ Match Co.: | P30261, P40312 |
| Ideal Disp / Mundean: | P-12481 |
| Johnstone Supply: | B10-333 |
| Kelvinator: | 719901 |
| La Crosse: | 97233 |
| Mills Indust.: | BD-5883 |
| Ranco: | 9531N388, A10-1613, A10-6170, A12-1500, A12-1503, A12-1520, A12-1521, A12-1555, A12-1556, A12-1558, A12-1562, A12-1565, A12-1571, A12-1579, A12-1579A, A12-1582, A12-1587, A12-1593, A12-1594, A12-1642, A12-1645, A12-1649, A12-1652, A12-1655, A12-1659, A12-1660, A12-1679, A12-1685, A12-1692, A12-1696, A12-1700, A12-1711, A12-1715, A12-1728, A12-1738, A12-1739, A12-500, A12-514, A12-517, A12-521, A12-561, A12-574, A12-577, A12-595, A12-605, A12-605A, A12-616, A12-616A, A12-634, A12-635, A12-700, A12700, A12-761, A19-100, CA-12-1515, CA12-1551, CA12-1632, CA12-957, K12-L1522, K12-L1528, K12-L1539, K12-L1700, K55Q-5618 |
| Rock-Ola Mfg. Co.: | V10169 |
| Ruslander & Sons Inc.: | CTL001 |
| Schaefer / Studebaker: | C11744-2 |
| Star Cooler Corp.: | SN-16150-CO |
| Steelmade: | 60-3-0-2 |
| Uni-Line: | K12L-1557-000U, 92024, 9997-001 |
| United Refrigeration: | P-2002B, P-3265D, P-3265-D, P-4308-B, P-4880-D |
| Universal Metal Prod.: | P-30261 |
| Vendo: | B42490-1, C338367, C521461-H, 35200, 35200H, 935200-H |
| W.W. Grainger: | 3XL05 |
