Description
ICM Controls ICM2904 Intermittent Pilot Gas Ignition Control
- Intermittent pilot gas ignition control module
- For use with intermittent pilot boilers, furnaces and other heating appliances
- Microprocessor-based
- Remote flame sensing
- Compatible with LP or natural gas
- Brown out monitoring
SPECIFICATIONS:
-
Control Voltage: 18-30 VAC
-
Frequency: 50/60 Hz
-
Pilot Valve: 2A @ 24 VAC
-
Main Gas Valve: 2A @ 24 VAC
-
Current Draw: 100mA maximum
-
Pre-Purge Delay: 0 seconds
-
Operating Temperature: -40°F to 167°F,-40°C to 75°C
-
Humidity: 5%-95% R.H. (non-condensing) at +55°C
REPLACES:
- Reznor: 257009
- UTEC: 1003-638A
