DiversiTech Asurity™ QUIETMINI-M Undermount, Ductless / Mini-Split Condensate Pump
$139.88
SKU QUIETMINI-M
DiversiTech Asurity™ QUIETMINI-M Undermount, Ductless / Mini-Split Condensate Pump
The Asurity® QUIETMINI-M Undermount Condensate Pump is designed to install under wall mounting type air conditioners and provide ultra-quiet running utilizing the new ultra-quiet technology along with a stylish, sleek design. These tank pumps offer easy installation, hassle free maintenance and serious ultra quiet pumping for the future. Perfect for those installations in quiet locations - hotels, theaters, bedrooms and meeting rooms.
Features
- Ultra Quiet, (21 dBA)
- Removable Reservoir for Easy Maintenance
- Built-In Safety Overflow Switch
- Max Unit Output 54,000 BTU/h, 16 kW
- User configurable flow - can be mounted on the right or left hand side of unit
- Consistent pumping performance operating from 90 to 240 VAC voltage level
- Universal voltage - 115 – 230V 60Hz
- Self-priming
- Compact Size with Diaphragm Technology
SPECIFICATIONS
| Color | White |
|---|---|
| Volts | 115 |
| 230 | |
| Application | Ductless |
| Under-Mount | |
| Hertz | 60 |
| UL Listed | No |
| Amps | 0.3 |
| Discharge Line (In.) | 1/4 |
| Floatless Sensor | No |
| High Level Switch | Yes |
| Input Type | Flying Leads |
| Max Flow Rate (GPH) | 4 |
| Max Lift Height (Ft.) | 26 |
| No. of Inlets | N/A |
| Self-Cleaning | No |
| Variable Speed and Lift | No |
| Max Unit Size (Tons) | 4 |
| Overflow Switch Circuit Classification | Class 2 |
| Safety Circuit Rating (A) | 3 |
| Sound Level dB(A) @ 3 Ft. | <21 |
| Suction Lift Height (Ft.) | 8 |
| Ducted or Ductless | Ductless |
| BTU / Hr Input | N/A |
| Primary Depth (inches) | 11.6 |
| Primary Width (inches) | 2.95 |
| Primary Height (inches) | 3.94 |
| Primary Weight (lbs) | 1.23 |
